Why ZWCAD?

ZWCAD is a budget-friendly, DWG file format-compatible Computer Aided Design (CAD) software for MCAD and AEC industries. It’s a reliable solution crafted for designers looking for an accessible and affordable drafting application with all the functionality of AutoCAD. The application brings the micro innovations you require to deliver smart and efficient design.

It provides a wide range of compact and lightweight drafting features that make it operate faster and overcome key CAD challenges. Some of its key features include 3D solid modeling, dimensioning, create and edit 2D geometric objects, file sharing, and plotting. In addition, ZWCAD comes with other innovative, customizable, collaborative features including tool pallets, design center, and API customization to boost your efficiency.

Comparison with AutoCAD

FEATURES	ZWCAD PRO	AutoCAD LT	AutoCAD FULL
Compatibility
Compatible with Any DWG versions	🗸	🗸	🗸
Compatible with DWT,DXF,DWF,DWFX	🗸	🗸	🗸
PDF&DGN Import	🗸	🗸	🗸
DWT support	🗸	🗸	🗸
Tools
Quick Properties Panel	🗸	🗸	🗸
Point Cloud	🗸	x	x
Area Table	🗸	x	x
ArcGIS Module	🗸	x	🗸
Associative Array	🗸	🗸	🗸
Data extraction	🗸	x	🗸
Etransmit	🗸	x	x
Quick Select	🗸	x	x
Settings Migration	🗸	x	x
Smart Mouse	🗸	x	x
Smart Select	🗸	x	x
Smart Voice	🗸	x	x
Interface
Classic and Ribbon Interfaces	🗸	🗸	🗸
Customize User Interface (CUI)	🗸	🗸	🗸
Properties Palette	🗸	🗸	🗸
Dynamic Input	🗸	🗸	🗸
Dark/Light UI	🗸	🗸	🗸
Tool Palettes	🗸	🗸	🗸
Auto-complete Command Entry	🗸	🗸	🗸
Lasso Selection	🗸	🗸	🗸
Adaptive Grid	🗸	🗸	🗸
Command auto complete	🗸	🗸	🗸
Design Center	🗸	🗸	🗸
Drawing tab switching	🗸	🗸	🗸
Dynamic UCS	🗸	🗸	🗸
Multi-thread CPU speed up	🗸	🗸	🗸
Partial CUI	🗸	🗸	🗸
Annotation
Enhanced coordinate dimension	🗸	X	X
Leader & MLeader	🗸	🗸	🗸
MleaderAlign	🗸	🗸	🗸
Revcloud	🗸	🗸	🗸
Text and MText	🗸	🗸	🗸
Hatch/Gradient Hatch	🗸	🗸	🗸
Associative Dimension	🗸	🗸	🗸
Annotative Scale	🗸	🗸	🗸
Super hatch	🗸	🗸	🗸
Tables & Table styles	🗸	🗸	🗸
Field	🗸	🗸	🗸
Enhanced grip editing menu	🗸	🗸	🗸
Pline and Hatch Boundary Grips	🗸	🗸	🗸
Text in-place editing	🗸	🗸	🗸
Layer
Layer Properties Manager (Classic)	🗸	🗸	🗸
Layer Properties Manager (Panel)	🗸	🗸	🗸
Layer Filter	🗸	🗸	🗸
Layer State Manager	🗸	🗸	🗸
Layer Walk	🗸	🗸	🗸
Layer Merge	🗸	🗸	🗸
Layer Browser	🗸	x	x
Vieport Layer	🗸	🗸	🗸
Xref, Block and Attribute
Underlay (DWG, DWF(x), PDF)	🗸	🗸	🗸
Multiple block inserting	🗸	x	🗸
Block Attribute Manager	🗸	🗸	🗸
OLE	🗸	🗸	🗸
Raster Images	🗸	🗸	🗸
Xrefs In-place Editing	🗸	🗸	🗸
3D modeling and Visualization
Solid, Surface, and Mesh modeling	🗸	x	🗸
Visual Style (Hide & Shade)	🗸	x	🗸
Photorealistic Rendering	🗸	x	🗸
ACIS Viewing	🗸	🗸	🗸
3D Orbit	🗸	x	🗸
Solprof	🗸	x	🗸
STL export	🗸	x	🗸
Z axis tracking	🗸	x	🗸
IFC Import	🗸	x	🗸
Programming Interface
Lisp Debugger	🗸	x	🗸
VBA support	🗸	x	x
(ZRX/ARX) support	🗸	x	🗸ARX
.NET support	🗸	x	x
Print
Batch Plot	🗸	x	x
CTB & STB plot styles	🗸	🗸	🗸
Export	🗸	🗸	🗸
Mv setup	🗸	🗸	🗸
Shade Plot	🗸	🗸	🗸
Plot to SVG	🗸	x	x
Plotting	🗸	🗸	🗸
Publish DWF/DWFx	🗸	🗸	🗸
Publish PDF	🗸	🗸	🗸
Innovation
SmartMouse/Voice/Select/Plot	🗸	x	x
Barcode & QR Code	🗸	x	x
Others
File Compare	🗸	🗸	🗸
Quick Select	🗸	🗸	🗸
Match Property	🗸	🗸	🗸
